Ultrasound Probe Problems: Identify Damaged or Broken Ultrasound Probe (Guide)
This article has been updated 29-03-2025
Have you got a broken ultrasound probe?
Or do you need to identify the error on your ultrasound probe so you can fix it?
Ultrasound transducers are, without a doubt, a vital part of a fully functional ultrasound machine.
In this post, we map out common ultrasound probe damages due to misuse, with pictures and descriptions of the failures and defects.
You might be able to fix the probe yourself.
If not, our team of specialists is ready to help you.
At LBN Medical, we can repair broken ultrasound probes and also provide you with new or used ones.
First of all, remember to handle ultrasound transducers with care to ensure they keep working at their best.
You should consider a set of precautions when working with ultrasound probes.
Such as:
- Use protective bags around the transducer head or attach safety wires to prevent dropping it on the floor.
There are some precautions you should not only consider but also strictly follow:
- Never use disinfectant fluids containing alcohol, as they will dry out the probe’s lens.
- Avoid bending and twisting the cable, as it contains 128-320 small wires connected to crystals. If these wires tear, the signal will be greatly reduced or even completely disappear.
And remember, rough and careless treatment of equipment is never covered by any warranty.
If you want to learn more about ultrasounds to help choose the right model, you can sign up for our email course.
Additionally, you will receive a free e-book, “Guide to Ultrasounds,” which only requires your email address.
Join the Ultrasound mail course
Broken Ultrasound Probe – Identify Ultrasound Probe Damage
In the table below, you can see examples of the most common ultrasound probe defects:
Crack in Housing of the Ultrasound Probe
Most probably, the probe has been dropped or hit by another object.
Dried-out Ultrasound Probe Lens
Using disinfectants unsuitable for transducer lenses, especially those containing alcohol, can dry out the ultrasound probe lens. If this occurs, sometimes you can restore it by using a proper gel.
Crack in the Ultrasound Probe
A crack in the ultrasound probe can cause noise, missing connections, or lines in the image. This issue often stems from a hole in the lens, which may result from an impact, a fall, wear and tear of the wires, or a sharp object like a scalpel cutting the wire.
Damaged Crystal in the Probe
This defect indicates dead, damaged, or weak crystals, often caused by dropping the probe on the floor or hitting the lens with a gel bottle.
Broken Ultrasound Probe Cable
A broken cable can cause noise, missing connections, or lines in the image. This is often due to a cart/system running over the cable, causing wear and tear. Prolonged exposure to pressure or impact can also cause the wires to stack together, distorting the cable’s shape and affecting its functionality.
Ultrasound Probe Artifact
Artifacts like noise or missing connections can occur if the strain relief breaks due to bending, a system runs over the cable, or the connector is dropped.
Ultrasound Probe Maintenance – Frequently Asked Questions
How to protect an ultrasound probe?
To protect an ultrasound probe, handle it with care, ensuring it is held securely to prevent drops. Use proper storage, such as a dedicated holder or case, when the probe is not in use. Clean the probe after each use with appropriate, non-abrasive cleaners and disinfectants, and avoid excessive bending or twisting of the probe cable.
Regularly inspect the probe for signs of wear and damage, and always follow the manufacturer’s recommendations for use and maintenance. These practices will help extend the life of the probe and ensure its optimal performance.
Can a broken ultrasound probe be repaired?
What happens if you drop an ultrasound probe?
Does alcohol damage ultrasound probe?
How long does an ultrasound probe last?
Sum Up – Ultrasound Probe Problems
Have you learned more about broken ultrasound probes and how to prevent their defects?
Please note, the explanations for broken ultrasound probes are not 100% definitive causes but are based on our technical department’s experience.
This is a list that our technical department has provided us with.
It contains the defects they commonly see on probes and a logical explanation of why they have appeared.
We always recommend treating your ultrasound transducers with care.
Moreover, we encourage you to only use them the way the manufacturer of the transducer proposes.
